[In Stock] DRK-601R Aluminum Mechanical Keyboard (Adapt to Wooting60 HE)

Marketplace New (in-stock) products
1

DRK-601R

Designed by Design Roost Studio

Discord | Instagram | TikTok | YouTube

Description

The DRK-601R is a vintage-styled aluminum alloy case kit designed for 60% keyboard layouts. It offers good compatibility and customizability. The designer has uniquely interpreted classic retro elements, providing users with a keyboard with a distinctive personality.

Color Options

Coconut Milk

Carmine

Ice Blue

Pale Green

More

Layout

  1. Suitable for 60% keyboard layouts, such as 64-key, 60-key, 63-key, HHKB, WKL, etc.

  2. The case size is within 286*96mm, compatible with various 60% PCBs.

  3. As long as the type-C port position of the 60% PCB is consistent with the type-C port position of the wooting60 HE PCB, it can be adapted to the DRK-601R. Or it will not work.

Examples of some compatible PCBs:
ISO64,  m6lite+, M6U, Pure64, Rakka64, wooting60

Switch Support

  1. Compatible with both magnetic and mechanical switch PCBs.
  2. Optimized design for magnetic switches.

Case Material and Design

  1. Dual-layer aluminum alloy case design.
  2. Design inspiration drawn from vintage Santana sedans, game consoles, and cassette tapes.
  3. Maintains a minimalist style while incorporating a touch of technology.

Accessories and Customizability

  1. Built-in Type-C interface.
  2. Comes with HHKB and WKL baffle, which can be installed by screws.
  3. Enhances the keyboard’s customizability and personalization.

Videos

Assemble

Typing sound

Specifications

Case Material: 6063 CNC Aluminum
Process: Anodizing(Wine) and sandblasting (Coconut Milk, Ice Blue, Pale Green )
Layout: 60% (The case is compatible with GH60 standard PCB)
PCB: Support WK, WKL, HHKB, 64% Layout, Capsled, Split spacebar, Split backspace, ISO Enter,  stepped capslock
PCB Thickness: 1.2mm
Support VIA: Yes
1.5mm FR4 Plate 5: 64% Layout 1,  HHKB1, WKL1, 60% layout common 1, 64% Layout+split spacebar+ISO enter1
Poron Foam: 3.5mm Poron Pad, 0.5mm IXPE Pad, 2mm Switch Pad, Poron bottom Pad, EVA Battery Compartment Filling Pad
Stabilizers: Factory Lubed
Battery: 3000 mAh
Typing Angle: 6.5°
Front Height: 18.45mm
Weight: 1.3kg (Case only)
Connectivity: Tri-mode
Polling rate: Wire/2.4G (1000hz), Bluetooth (125hz)
Delay: 8-10ms (2.4G), 22ms (BT)

Including

Keyboard case
Mechanical PCB
FR4 Plate *5
Case Foam *5
Gasket Silicone
Stabilizers
3000 mAh Battery
Silicone feet
Type C USB Cable
Screwdriver and Allen key, spare screws, washers
Switches/Keycaps Puller
Gift: HHKB, WKL removable baffle

Assembly Instructions

Price Info

Price: 169USD

Purchase
