Hello everyone,

I am so excited to announce that MKC’s second series-MKC65 will be available to everyone in two days! If you are looking for a truly entry-level customized keyboard, I believe it will not disappoint you. Without further ado, read on for more details about the MKC65 pre-order.

MKC65 Pre-order information

First Week Pre-order Bonus:

An MKC Titanium Switch Puller

Pre-order Time:

From January 15th to February 15th

Estimated Delivery:

The delivery is expected to be around two months after the pre-order ends. Due to the influence of the Spring Festival holiday and potential adjustments in the order quantity, there might be a slight variation in the delivery time.

Vendor List

MKC65 information

Features

  • Compact 65% layout.
  • 6.5° typing angle for a more comfortable typing experience.
  • 100% CNC-machined with 6063 aluminum case.
  • Alu Internal Weight, adding to the overall weight and stability.
  • Simultaneously support two functional modules (Rotary Knob & Light Sign), also compatible with JRIS80 Rotary Knob/LED Light Sign.
  • Three-in-one design with Top Mount, Plate Gasket Mount, and PCB Gasket Mount for an enhanced keyboard experience.
  • Supports tri-mode PCB (Wired, Bluetooth and 2.4ghz).
  • Supports Plate and Plateless Build.
  • Supports Caps Lock Indicator Light.
  • 2 x 2200mha large battery capacity.

MKC65 Specifications

  • Typing angle: 6.5°
  • Front height: 9 mm
  • Material: Full CNC 6063 aluminum
  • Dimension: 319.85110.329.95mm
  • Three-in-one Structure: TOP Mount / Plate Gasket Mount / PCB Gasket Mount
  • QMK/VIA Supported（wired）
  • Support PCB stabilizers
  • Unbuilt Weight

With PVD WEIGHT: 1.23kg

With Alu WEIGHT: 1kg

  • Built Weight

With PVD WEIGHT: 1.45kg

With Alu WEIGHT: 1.22kg

Three-in-one Structure

Three-in-one structure (Top Mount, Plate Gasket Mount, and PCB Gasket Mount) is a versatile keyboard mounting system that combines the distinctive features of these three structures for comprehensive performance. Users can customize based on personal preferences and usage scenarios.

Support Rotary Knob & LED Light Sign at the same time

The four keys located on the rightmost row of the MKC65 keyboard (Insert, Delete, PgUp, and PgDn keys) can function as a customizable module. The Rotary Knob and Light Sign can be interchanged among any four keys, and they don’t necessarily need to be connected together.

However, please note that it supports a maximum of two functional modules simultaneously. For example, 2 * Rotary Knob, 2 * Light Sign, or 1 * Rotary Knob + 1 * Light Sign.

What can you customize for MKC65?

8 Case Options:

8 Weight Options:

5 PCB Options:
  • Wired Flex Cut Hotswap PCB( 1.2mm, Multi Layout , 7u split spacebar, No Per-key RGB, support QMK and VIA )
  • Wired Non-Flex Cut Hotswap PCB(1.6mm, Multi Layout, 7u split spacebar, No Per-key RGB, support QMK and VIA )
  • Wired Solder PCB(1.6mm, Non-Flex Cut, Multi Layout, 7u split spacebar, No Per-key RGB, support QMK and VIA )
  • Wired Per-Key RGB Hotswap PCB (Add-on only, 1.6mm, Non-Flex Cut, ANSI Layout, support QMK and VIA )
  • Tri-mode Hotswap PCB (1.2mm, Non-Flex Cut, ANSI Layout, No Per-key RGB, support Mykeyclub Software）Noted: The Tri-mode technical support is provided by IRISLab.
5 Plate Options:

Noted: We highly recommend using a PC/ POM/FR4 plate for Tri-mode PCB because the Brass and ALU plate will have a little affection for connectivity.

What’s Included in MKC65?

  • Full CNC Aluminum Top case *1
  • Full CNC Aluminum Bottom case *1
  • Weight (Anodized Alu Weight or Stainless steel PVD Weight) *1
  • Internal Alu Weight *1
  • PCB *1
  • Plateless or Plate *1
  • IXPE Foam *1
  • Poron Case Foam *1
  • Poron Plate Foam *1
  • Type-C Daughterboard with JST Cable *1
  • PCB GAS Silicone Column *12
  • Plate GAS Silicone Sock *18
  • Top mount screw and spacer *12
  • PCB stabilizers o-ring *12
  • Footpad *6
  • Poron case strip *6
  • 1.5mm hex key *1

Gift(will not send make-up or replacements)

  • 1 MKC Stabilizer Set
  • 1 Type-C Cable
  • 1 Pack of Extra Screw

M2x3mm cylindrical head screw *2

M2x8mm cylindrical head screw *2

M3x5mm countersunk screw *2

  • 1000mha battery (Only for the Tri-mode Version Case) *2
  • Silicone pad of battery compartment *2

Review links (Stay Tuned for More)

  • Simulator Tech: Black Case+ Gold PVD weight
  • Rx003: Grey Case+ Black PVD weight
  • apiarykeyboards: Mint Green Case+ Silver PVD weight
  • dutchmasterw: Black Case+ Silver PVD weight
  • 바룬 Baroon: Silver Case+ Silver PVD weight
  • Captain Sterling: Grey Case+ Rose Gold Alu weight
  • Merkeebs: Black Case+ Chroma PVD weight
  • Clackbait: Silver Case+ Chroma PVD weight
  • MechTech Keyboards: E-White Case+ Black PVD weight
  • Edward Tanujaya: Black Case+ Black PVD weight
  • kittykat.keys: Wine Red Case+ Gold PVD weight
  • Zeke DGTL: Milky White Case+ Rose Gold Alu weight
  • Nicola Sagliano: Wine Red Case+ Black PVD weight
  • Nextrift: Wine Red Case+ Black PVD weight
  • MCZ Studio: Milky White Case+ Gold PVD weight
  • Custom Ton Clavier: E-White Case+ Gold Alu weight
  • strawberryjam1986: Milky White Case+ Gold PVD weight
  • Lattech 라떼크: Silver Case+ Chroma PVD weight

Mykeyclub Team

We are a platform that integrates creativity and innovative design, helping more studios join this hobby community and bringing more fun and cool products to you guys. Please participate in our MKC family for more discussions and future updates.
